Description
Precision
Production with unrivalled accuracy thanks to a sophisticated substrate handling system for class-leading performance. Featuring a highly advanced auto-tension control (AD-ATC) system, wide-diameter feed rollers and anti-static flexible pressure rollers to optimise grip feed and accuracy.
Quality
Featuring the latest generation dual Epson PrecisionCore TFP printheads, the SC-S80610 produces outstanding output with superb colours and clarity. Working in tandem with new formulation Epson UltraChrome GS3 with Red inks, users can produce a wide range of highly accurate colours. Improving the quality on a range of substrates is possible thanks to the printers’ Precision Dot high-quality mode.
Productivity
Automated printhead maintenance and an ink mist collection system help ensure continued printing for maximum uptime.
PRODUCT SPECIFICATIONS
| Printing Method |
MicroPiezo TFP print head |
| Ink Technology |
UltraChrome® GS3 with Red |
| Color |
Black, Light Black, Metallic Silver, Cyan, Light Cyan, Yellow, Magenta, Light Magenta, Red, Orange, White, Cleaning liquid |
| Ink tank capacity |
700 ml |
| Minimum Droplet Size | 4,2 pl, With Variable-Sized Droplet Technology |
| Printing Resolution | 1.440 x 1.440 DPI |
| Print Margins Roll Media | Mode 1: 5 mm (top), 3 mm (right), 5 mm (bottom), 3 mm (left) |
| Compatible Paper Thickness | 0,1 mm - 1.000 mm |
| Paper Formats | 64" |
| Energy Use | 650 Watt, 380 Watt (economy), 14 Watt (standby), 1,5 Watt (Power off) |
| Product dimensions | 2.620 x 1.090 x 1.311 mm (Width x Depth x Height) |
| Product weight | 279 kg |
| Included Software | Epson Edge Print |
| Compatible Operating Systems | Mac OS 10.4+, Windows 7, Windows 7 x64, Windows Vista, Windows Vista x64, Windows XP, Windows XP x64 |
| Interfaces | USB 2.0 Mini-B, USB 2.0-A, Ethernet interface (100 Base-TX / 10 Base-T) |
| What's in the box | Driver and utilities (CD), individual ink cartridges, installation/safety manual, main unit, power cable, setup guide, user manual (CD), warranty documents |
KEY FEATURES
Precise and accurate printing
- Class-leading AD-ATC system andsophisticated media feeding
Superior-quality results
- Latest generation PrecisionCore TFP printheads and UltraChrome GS3 with Red inks
Range of creative applications
- Print on substrates including clear film, vinyl, canvas and photographic paper
Maximise productivity
- Automated printhead maintenance and guard plate; ink mist collection system
Exceptional service and support
- Two year warranty as standard with extended options available
Downloads
To download the latest product brochure, Click Here
