Description
Prices include VAT and 1 year Warranty. Installation is excluded. Please contact us for Installation pricing.
Extreme simplicity:
- Print multi-size A3/B and A1/D or A0/E projects automatically, without manually switching the media source.
- Save time with the world's easiest job submission —send multiple files in one click with HP Click.
- Print with confidence you'll get the results you expect with an intuitive driver and true print preview.
Fits your office and budget:
- Save space with the world's smallest plotters designed to fit your office, including a built-in stand.
- Use up to 95% less ink for routine maintenance vs competitors and get up to 100 extra A1/D pages per month.
- More sustainable design reduces CO2e up to 7.3 tons/year by units sold by using up to 30% recycled plastic.
Fits the way you work:
- Avoid waiting by the printer with high-speed printing as fast as 30 seconds per A1/D plot.
- Be more productive—save time from job prep to final print by printing your projects up to 2X faster.
- Print your jobs and manage your plotter from virtually anywhere, anytime with the HP Smart app.
- Get high-quality results—HP Bright Office Inks plot up to 31% more line accuracy and up to 65% more gamut.
Technical specifications
| Functions |
|
| Print speed, maximum |
30 sec/page on D, 76 D prints per hour |
| Resolution (color) |
Up to 2400 x 1200 optimized dpi |
| Print Technology |
HP Thermal Inkjet |
| Number of print cartridges |
4 (C, M, Y, K) |
| Product disclaimer |
This printer is intended to work only with cartridges that have a new or reused HP chip, and it uses dynamic security measures to block cartridges using a non-HP chip. Periodic firmware updates will maintain the effectiveness of these measures and block cartridges that previously worked. A reused HP chip enables the use of reused, remanufactured, and refilled cartridges. More at:http://www.hp.com/learn/ds |
| Compatible ink types |
Dye-based (C, M, Y); pigment-based (K) |
| Print languages |
HP-GL/2, HP-RTL, CALS G4, JPEG, URF |
| Connectivity, standard |
Gigabit Ethernet (1000Base-T), Hi-Speed USB 2.0, Wi-Fi 802.11a/b/g/n, Wi-Fi Direct |
| Memory, standard |
1 GB |
| Hard disk |
none |
| Non-printable area (cut-sheet) |
0.2 x 0.2 x 0.2 x 0.2 in |
| Line accuracy |
±0.1% |
| Maximum optical density (black) |
8 L* min/2.10 D |
| Dimensions (W X D X H) |
39.9 x 23.8 x 36.7 in |
| Finished output handling |
Sheet feed, roll feed, automatic sheet feeder, media bin, automatic horizontal cutter |
| Media sizes supported |
Auto sheet feeder: A, B; manual feed: A, B, C, D, E |
| Media sizes supported |
Auto sheet feeder: A4, A3; manual feed: A4, A3, A2, A1, A0 |
| Media sizes, custom |
Auto sheet feeder: 8.3 x 11 to 13 x 19 in; manual feed: 8.3 x 11 to 36 x 74.7 in |
| Media types |
Bond and coated paper (bond, coated, heavyweight coated, plain, bright white, blueprint), technical paper (natural tracing), film (clear, matte), photographic paper (satin, gloss, semigloss, polypropylene), self-adhesive (adhesive, polypropylene) |
| Power |
Input voltage (auto ranging): 100-240 V (±10%), 50/60 Hz (±3 Hz), 1200 mA max. Not dual voltage, power supply varies by part number with # Option code identifier. |
| Warranty |
One-year limited hardware warranty |
| Weight |
76.5 lb |
| What's in the box |
HP DesignJet T630 36-in Printer, printer stand, automatic sheet feeder, printhead, introductory ink cartridges, spindle, quick reference guide, setup poster, power cord |
